WIP026SF

• 1/2.7" 2Megapixel progressive CMOS

• H.265+ & H.265 dual-stream encoding

• 25/30fps@1080P(1920x1080)

• DWDR, Day/Night(ICR), 3DNR, AWB, AGC, BLC

• Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

• 3.6 mm fixed lens

• Max IR LEDs Length 30m

• IP67, PoE

System Overview

The IR Megapixel Fixed camera delivers 2MP/4MP resolution with a motorized 3.6mm fixed lens. The camera's elegant blend of aesthetics combined with a range of easy mounting solutions provides an excellent choice for a variety of small to mid-size applications at an affordable price.

Functions
Smart Codec (H.265+ & H.264+)
Smart Codec is the optimized implementation of standard video compression (H.265 & H.264) that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart Codec technology reduces bit rate and storage requirements by up to 70% when compared to the standard video compression.

True Day/Night
A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens

Regions of interest
Regions of Interest (ROI) is a user defined feature that allows the operator to monitor specific areas of a scene while still maintaining overall situational awareness of less important areas

Smart IR
With IR illumination, detailed images can be captured in low light or total darkness. The camera's Smart IR technology adjusts to the intensity of camera's infrared LEDs to compensate for the distance of an object. Smart IR technology prevents IR LEDS from whiting out images as they come closer to the camera. The camera's integrated infrared illumination provides high performance in extreme low-light environments up to 30m (98ft).

Image flip
Capturing unnecessary data such as surrounding hallway walls can increase storage requirements without any added value. The image flip feature allows the camera's image to be rotated in 90 ํ increments for better video optimization.

Environmental
WATASHI cameras operate in extreme temperature environments, rated for
use in temperatures from -30~ C to +60~ C (-22' F to +140~ F) with 95% humidity.

Protection (IP67, wide voltage)
The camera allows for t25% input voltage tolerance, suitable for the most unstable conditions for outdoor applications. Its 2KV lightning rating provides effective protection for both the camera and its structure against lightning. Subjected and certified to rigorous dust and immersion tests (IP67) .

Interoperability
The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interopera bility between network video products regardless of manufacturer

Techical Specification
